German Standard DIN F4 Bronze Gland Gate Valve with Gland-Type Pressure Seal and Full-Bore Design for Efficient Flow Control
| Place of Origin | China |
|---|---|
| Brand Name | YOUWEI |
| Certification | CE EAC |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Casting,Brass,Stainless Steel,Ductile Iron,GGG40 | Port Size | DN50-DN1200,Standard,2"-24" |
|---|---|---|---|
| Power | Manual,Electrical Actuated,Hydraulic,Handwheel Operated,GO | Pressure | Medium Pressure,Low Pressure,PN10-16,PN1.0/PN1.6,250PSI |
| Temperature Of Media | Medium Temperature,Normal Temperature,Low Temperature,-10~100℃ | Media | Water,Oil Etc.,Gas And So On |
| Application | General,irrigation,water Distribution,Industry,Water System | Structure | Gate,Butterfly,Non-Rising Gate Valve |
| Standard Or Nonstandard | Standard | Product Name | Gate Valve,Cast Iron Electric Gate Valve With Non-rising Stem DN40-DN600,DIN/BS Double Socket Type Resilient Seat Gate Valve,steel 2cr13 Stem Handwheel Api 6a Welhead Safety Gate Valve Stem Cap,3/4" Cast Iron Handle OEM 200 Wog Home Depot Brass Gate Valve |
| Standard | DIN,BS,JIS,F5;AWWA C509/C515;ANSI,DIN3352 | Size | DN40-DN600,DN50 ~ DN 1000,2''-24'',DN15 To100 |
| Connection | Flange Ends,Double Flanged,BSP,Socket Ends,Female Thread | Body Material | Ductile Iron,DI/CI,DI,cast Iron,Brass |
| Color | Blue,Customer's Request,Customer's Requirement,Yellow,GREY | Medium | Water,Water Oil Gas |
| Type | Gate Valve,Normal Open,2-way,Non-Rising Stem/ NRS | Valve Type | Gate Valve |
| Seal | Rubber Lined,Metal,PTFE | ||
| Highlight | DIN F4-grade bronze Gate Valve,Gland-Type Pressure Seal Bronze Gland Gate Valve,Full-Bore Design DIN F4 Gate Valve |
||
Product Description
German Standard F4 Copper Bonnet Gate Valve
High Sealing Durable Pipeline Control Valve for demanding industrial applications
Product Overview
Our German Standard DIN F4 Bronze Gland Gate Valve delivers reliable, long-lasting isolation in industrial, commercial, and marine piping systems. Constructed from high-grade bronze with a gland-type pressure seal design, this valve ensures superior leak-tightness, excellent corrosion resistance, and easy maintenance for water, oil, gas, steam, and other non-aggressive media applications.
Key Features & Technical Advantages
- Premium Material Construction: DIN F4-grade bronze (Rg5) body, bonnet, and gland for optimal strength, machinability, and corrosion resistance
- Gland-Type Pressure Seal Design: Bolted gland flange and stuffing box system for precise packing adjustment and in-field maintenance
- Full-Bore Design & Efficient Flow: Smooth full-port design minimizes pressure drop and allows easy pipe cleaning
- Rising Stem & Visual Indication: Outside Screw and Yoke (OS&Y) design provides clear valve position indication with isolated stem threads
- Robust Sealing & Durability: Precision-machined bronze wedge/disc and seat rings for bubble-tight sealing and extended service life
- Standard Compliance & Interchangeability: Manufactured to German DIN standards (DIN 3352, DIN 3202) for perfect compatibility
- Versatile End Connections: Available with DIN threaded ends (DIN 2999) or DIN flange connections (DIN EN 1092-2)
Technical Specifications
| Design Standard | DIN 3352 / DIN 3202 |
| Body Material | Bronze F4 (Rg5) - CuZn39Pb3 |
| Seat & Wedge | Bronze |
| Stem | Bronze |
| Packing | Graphite-Impregnated Braided Asbestos-Free Packing |
| Pressure Rating | PN 16 / PN 25 (Standard) |
| Temperature Range | -20°C to +200°C |
| Operation | Handwheel (Standard), Gear Operator (Optional) |
| End Connections | DIN Thread (DIN 2999) or DIN Flange (DIN EN 1092-2) |
| Media | Water, Steam, Oil, Gas, Non-aggressive Chemicals |
Typical Applications
Industrial Process Water & Cooling Systems
HVAC and Building Services Plumbing
Marine & Offshore Piping Systems
Chemical & Petrochemical Plants
Fire Protection and Water Supply Networks
Compressed Air and Inert Gas Systems
Why Choose Our Valve?
This gate valve combines German engineering precision with robust metallurgy. The gland design ensures long-term seal integrity and serviceability, while F4 bronze construction provides proven performance in corrosive environments. A dependable, standardized component designed to reduce maintenance costs and system downtime.
